KTM 1190 RC8 R User Manual

10 TUNING THE CHASSIS 165
B01318-12
–
Tighten screws

on the left and right sides of the vehicle.
Guideline
Screw, subframe M8 20 Nm
(14.8 lbf ft)
Loctite
®
243™
Info
Check the cable routing; the lambda sensor cable should not be taut.
305720-10
–
Mount rubber cover

in the vacant threaded holes on both sides.
B01317-11
–
Position bushings

.
–
Mount and tighten screws

.
Guideline
Remaining chassis screws M6 10 Nm (7.4 lbf ft)

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
