KTM 1190 RC8 R User Manual

10 TUNING THE CHASSIS 164
B01318-13
Lowering the seat position:
–
Remove screws

with the washers on the left and right sides of the vehicle.
– Push down on the subframe until the drilled holes of the frame are aligned with the
holes at the top rear of the subframe.
– Mount the screws with the washer on the left and right sides of the vehicle but do
not tighten yet.
B01318-14
–
Remove screws

with the washers on the left and right sides of the vehicle.
– Push up on the subframe until the drilled holes of the frame are aligned with the
holes at the top front of the subframe.
B01319-01
– Mount and tighten the screws with the washers on the left and right sides of the
vehicle.
Guideline
Screw, subframe M8 20 Nm
(14.8 lbf ft)
Loctite
®
243™

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
