2MV
1-3-33
U031 Checking switches and sensors for paper conveying
Description
Displays the on-off status of each paper detection switch or sensor on the paper path.
Purpose
To check if the switches and sensors for paper conveying operate correctly.
Method
1. Press the start key.
2. Turn each switch or sensor on and off manually to check the status.
When a switch or sensor is detected to be in the ON position, the display for that switch or
sensor will be “1”.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Switches and sensors
Regist
Registration sensor (RS)
Fuser
Fuser pre sensor (FUPS)
Duplex
Duplex sensor (DUS)
Feed2
Feed sensor 2 (FS2)
FeedDown Tray Full
Paper full sensor (PFS)
Job Separator Full
JOB paper full sensor (JPFS)
Bridge Exit
Bridge eject sensor (BRES)
Fuser Jam
Eject sensor (ES)
Feed
Feed sensor (FS)
