U150 Checking sensors for toner
Description
Displays the on-off status of each sensor or switch related to toner.
Purpose
To check if the sensors and switches operate correctly.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
Method: [T/C]
1. Turn each switch or sensor on and off manually to check the status.
When a switch or sensor is detected to be in the ON position, the display for that switch or
sensor will be “1”
2. To stop motor driving, press the stop key.
Item No. Description
Display Description
T/C
Displays the state of the toner sensor.
Waste Box
Displays the state of the waste toner box.
Display Switches and sensors
T/C Sensor (C)
Displays the state of the toner sensor (Cyan).
T/C Sensor (M)
Displays the state of the toner sensor (Magenta).
T/C Sensor (Y)
Displays the state of the toner sensor (Yellow).
T/C Sensor (K)
Displays the state of the toner sensor (Black).
Motor
Drives developer motor, developer clutch.
Last print (C)
Displays the state of the toner sensor at the time of the last
printing (Cyan).
Last print (M)
Displays the state of the toner sensor at the time of the last
printing (Magenta).
Last print (Y)
Displays the state of the toner sensor at the time of the last
printing (Yellow).
Last print (K)
Displays the state of the toner sensor at the time of the last
printing (Black).
To Next Page
