2MV
1-3-164
U698 Setting the port addressed in maintenance mode
Description
Configures the port that is addressed in maintenance mode.
Purpose
To configure the port that is addressed in maintenance mode when the optional dual FAX is
installed.
It is not required to assign the same settings to both ports. It should be used to assign different
settings to each port.
Remarks
This maintenance item is shown only when the optional dual FAX has been installed.
Setting
1. Press the start key.
2. Press [PORT SELECT]. The current setting is displayed in reverse.
3. Select the item to be set.
Initial setting: ALL
4. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Supplement
The setting must be made after re-entering maintenance mode because it will be cleared when
maintenance mode is canceled and power is switched off.
Item No. Description
Display Description
ALL All ports
PORT 1 Port 1 (Fax control PWB)
PORT 2 Port 2 (Optional dual FAX)
