2MV
1-3-91
U244 Checking the DP switches
Description
Displays the status of the respective switches in the DP.
Purpose
To check if the respective switches in the DP operate correctly.
Method
1. Press the start key.
2. Turn each switch or sensor on and off manually to check the status.
When a switch or sensor is detected to be in the ON position, the display for that switch or
sensor will be “1”.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U245 Checking messages
Description
Displays a list of messages on the touch panel of the operation panel.
Purpose
To check the messages to be displayed.
Method
1. Press the start key.
2. Change the message using the cursor up/down keys.
When a message number is entered with the numeric keys and then the start key is pressed,
the message corresponding the specified number is displayed.
3. Change the language using the +/- keys.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Switches and sensors
Feed
DP paper feed sensor (DPPFS)
Regist
DP registration sensor (DPRS)
Timing
DP timing sensor (DPTS)
Set
DP original sensor (DPOS)
Longitudinal
DP original size length sensor (DPOLS)
Cover Open
DP interlock switch (DPILSW)
Open
DP open/close sensor (DPOCS)
To Next Page
