Kyocera TASKalfa 2550ci - Machine (Rear Side)

2MV
1-1-8
(2) Machine (rear side)
Figure 1-1-3
OPT2
OPT1
B1A2
39
43
44
45
49
47
50
46
48
41
42
40
51
39. Main power switch
40. Scanner lock lever
41. DP interface connector
42. DF interface connector
43. Cassette heater switch (cover)
44. Outlet connector
45. Inlet connector
46. Network interface connector
47. USB port
48. USB interface connector
49. Option interface slot 2
50. Option interface slot 1
51. FAX memory cover
