U053 Setting the adjustment of the motor speed
Description
Performs fine adjustment of the speeds of the motors.
Purpose
Basically, the setting need not be changed. Modify settings by interlock setting only if faulty
images occur.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
Setting
1. Select the item to be adjusted.
2. Change the setting value using the +/- keys or numeric keys.
3. Press the start key. The value is set.
Completion
Press the stop key. The indication for selecting a maintenance item No. appears.
Item No. Description
Display Description
Full
Speed correction value setting at full velocity
Half
Speed correction value setting at half velocity
3/4
Speed correction value setting at 3/4 velocity
Display Description
Setting
range
Initial set-
ting
Feed
Conveying motor 1 (CM1) speed adjustment -50 to 50 -1/-3/-1
Exit Eject motor (EM) speed adjustment -40 to 40 -3/-2/-3
Drum(CMY)
Drum motor (DRM-YCM) speed adjustment -50 to 50 -5/-2/-4
Drum(K)
Drum motor (DRM-K) speed adjustment -50 to 50 -5/-2/-4
DLP(CMY)
DLP motor (DEVM-YCM) speed adjustment -50 to 50 -3/-1/-2
DLP(K)
DLP motor (DEVM-K) speed adjustment -50 to 50 -3/-1/-2
Fixing
Fixing motor(FUM) speed adjustment -50 to 50 13/3/10
Feed2
Conveying motor 2 (CM2) speed adjustment -50 to 50 0/0/0
