2MV
1-2-4
1. Remove seven tapes.
Figure 1-2-4
2. Open the DP top cover.
3. Slide two DP original width guides and
then remove the pad.
4. Close the DP top cover.
Figure 1-2-5
Remove the tapes and spacer
Tape
Tape
Tape
Tape
Tape
Tape
Tape
DP top cover
Pad
DP original width guides
