Kyocera TASKalfa 2550ci - Page 441

2MV
2-3-6
YC16
17 A3 O 0/3.3 V DC(pulse)
Address bus signal
Connected to
CF card
18 A2 O 0/3.3 V DC(pulse)
Address bus signal
19 A1 O 0/3.3 V DC(pulse)
Address bus signal
20 A0 O 0/3.3 V DC(pulse)
Address bus signal
21 D0 I/O 0/3.3 V DC(pulse)
Data bus signal
22 D1 I/O 0/3.3 V DC(pulse)
Data bus signal
23 D2 I/O 0/3.3 V DC(pulse)
Data bus signal
24 WP O 0/3.3 V DC Control signal
25 /CD2 O 0/3.3 V DC Control signal
26 /CD1 O 0/3.3 V DC Control signal
27 D11 I/O 0/3.3 V DC(pulse)
Data bus signal
28 D12 I/O 0/3.3 V DC(pulse)
Data bus signal
29 D13 I/O 0/3.3 V DC(pulse)
Data bus signal
30 D14 I/O 0/3.3 V DC(pulse)
Data bus signal
31 D15 I/O 0/3.3 V DC(pulse)
Data bus signal
32 /CE2 O 0/3.3 V DC Control signal
33 /VS1 O 0/3.3 V DC Control signal
34 /IORD O 0/3.3 V DC Control signal
35 /IOWD O 0/3.3 V DC Control signal
36 /WE O 0/3.3 V DC Control signal
37 RDY /BSY I 0/3.3 V DC Control signal
38 VCC O 0/3.3 V DC Control signal
39 /CSEL O 0/3.3 V DC Control signal
40 /VS2 O 0/3.3 V DC Control signal
41 RESET I 0/3.3 V DC Reset signal
42 /WAIT O 0/3.3 V DC Control signal
43 /INPACK O 0/3.3 V DC Control signal
44 /REG I 0/3.3 V DC REG signal
45 BVD2 O 0/3.3 V DC Control signal
46 BVD1 O 0/3.3 V DC Control signal
47 D8 I/O 0/3.3 V DC(pulse)
Data bus signal
48 D9 I/O 0/3.3 V DC(pulse)
Data bus signal
49 D10 I/O 0/3.3 V DC(pulse)
Data bus signal
50 GND - - Ground
Connector Pin Signal I/O Voltage Description
