Kyocera TASKalfa 2550ci - Page 443

2MV
2-3-8
YC27
1 GND - - Ground
Connected to
hard disk
2 +5V_HDD O 5 V DC
5 V DC power output to HDD
3 GND - - Ground
YC30
1+5V O5 V DC
5 V DC power input from OPPWB-M
Connected to
operation
panel PWB
main
2+5V O5 V DC
5 V DC power input from OPPWB-M
3+5V O5 V DC
5 V DC power input from OPPWB-M
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
Connector Pin Signal I/O Voltage Description
