6.9.5.2. Digital Outputs
Configure Digital Outputs as needed per application. Digital outputs can be classified
as either Normally Open (NO) or Normally Closed (NC).
Digital Output Options
Digital Output
Comments
Reject 1
Turn on when leak rate is below user defined limit, level 1
Reject 2
Turn on when leak rate is below user defined limit, level 2
Reject 3
Turn on when leak rate is below user defined limit, level 3
Ready to Start
Status is standby.
In test
Status is in-cycle.
In final test mode
Mode is in test mode as set.
LD error
Leak detector has reported an error.
Calibrate ACK
Calibration ACK received. User must respond.
LD error or warning
Leak detector has reported a warning.
Calibration Active
Calibration in progress.
Sniff Active
Leak Detector is in sniff method.
HV active
Leak Detector is in vacuum method.
Fil 1 active
Filament 1 is active.
Fil 2 active
Filament 2 is active.
Start Up
System is in Startup Initialization.
Shutdown
System is in Shutdown / Power down.
None
