LACO Technologies TITAN VERSA C - Feature Locations and Dimensions

4 DESCRIPTION
LACO Technologies TITAN VERSA Operations and Maintenance Manual 13
Feature Locations and Dimensions
4.3.1.1. VERSA C Features and Dimensions
ID
Feature
1
Vacuum test port
2
Sniff test port
3
USB Port
4
Display and Cycle Start button
5
Product label
6
Power entry module
7
Multi-Use ports – Area 1
9
Electrical Interface
12
Fan inlet with filter
14
External pump port
15
Secondary external pump port (for High-Flow)
