8 MAINTENANCE AND SERVICE
130 TITAN VERSA Operations and Maintenance Manual LACO Technologies
Removing Back Cover (Tower Configuration)
In addition to removing the upper back and front covers shown in the section above,
the tower configuration has two lower covers.
1. Remove the lower back cover using a 6 mm Hex wrench to remove the 4 M8
screws. Pull off the panel.
2. Use a 5 mm Hex wrench to remove the four M6 screws located inside of the
bottom compartment and slide the plastic cover forward off the leak detector.
