5 INSTALLATION
40 TITAN VERSA Operations and Maintenance Manual LACO Technologies
Wireless Handheld Pendant
When configuring the Wireless Handheld Pendant, use only the wireless connection
option and hardware. To connect the Wireless Handheld Pendant:
1. Power on the leak detector
2. Connect the serial to Bluetooth adapter into wireless remote male DB9 port and
power on the adapter. Note the MAC address.
3. Power on the remote.
4. From the list, select the correct MAC address. Unit is connected wirelessly and
directs to home page.
Refer to the RC10 Manual (P/N: 124628) for more information.
Figure 9: Wireless Handheld Pendant
