5 INSTALLATION
LACO Technologies TITAN VERSA Operations and Maintenance Manual 33
TITAN VERSA Electrical Interface Summary
ID
Interface
Connection Type
Part Number
1
USB Host
USB Type A (2.0)
• TV5928 (4 GB)
2
Barcode Reader (1D
and 2D)
DB9, male
• TV118566
3
Accessory 1 & 2
M8, 3 pin, female
• TV5942 (screw terminal connector)
• TV5945 (5M cable)
• See Accessory Table – Accessory 1
and 2 items
4
Wireless Pendant
DB9, male
• TV118486
5
Remote Wired
Screen
M8, 4 pin, female
• TV115895 (module)
• TV5843 (1 m cable)
• TV5844 (3 m cable)
• TV5845 (5 m cable)
6
Serial (RS232 and
RS485)
DB9, female
• TV5946 (3 m M-F cable)
• LMSA0360 (USB to serial adapter)
7
Ethernet
RJ45
• LMSA3508 (3 m Cable)
8
Remote I/O
(8 digital inputs,
8 digital outputs,
2 analog outputs)
M12, 5 pin, female
• TV115893 (module)
• TV5839 (1 m cable)
• TV5840 (3 m cable)
• TV5841 (5 m cable)
9
Local I/O
M12, 8 pin, female
• TV5944 (screw terminal connector)
• TV5943 (5 m cable)
• TV118379 (Start / Stop box)
USB Port
A USB host port is provided next the sniffer port on the front of the unit. The user shall
only plug in a USB drive to the port. No other USB devices are supported. The USB port
is provided for the following features:
• Data Log Settings
• Software Updates
LACO provides a USB drive (P/N: TV5928) with shipment of each unit. This drive
contains TITAN VERSA documentation files and can also be used in conjunction with
data logging and software updates.
Local I/O
The TITAN VERSA is equipped with a local I/O on the M8 pin per table below. The local
I/O is provided primarily for the analog output features. See Local I/O for configuring
local analog inputs.
For traditional leak detector I/O, see Remote I/O.
