5 INSTALLATION
LACO Technologies TITAN VERSA Operations and Maintenance Manual 27
5.2.3.1. VERSA C (Compact) High-Flow Evac
The default configuration for the VERSA C (Compact) is the single pump configuration
(using lower port). If the user desires faster cycle times or is testing a contaminated
part, a two-pump configuration may be used. The smaller pump should be connected to
the higher port and the larger pump to the lower port.
All Compact High-Flow Evac configurations include a conversion kit. Follow the steps
below to convert to a two-pump configuration.
1. Remove back cover.
2. Remove hose assembly.
3. Install KF-16 blank off on bottom elbow assembly.
4. Install bent elbow nipple in vacuum block.
5. Install back cover.
6. Connect smaller pump to upper KF-25 port.
7. Connect larger pump to lower KF-25 port.
5.2.3.2. VERSA T (TOWER) High-Flow Evac
The VERSA T model requires an external pump. Connect the external pump to the
KF-25 port on the back cover. Ensure all connections are leak tight.
5.2.3.3. VERSA L (HORIZONTAL) High-Flow Evac
The VERSA L model uses the internal pump only. No external connections are needed.
Sniffer Port
1. Connect the sniffer probe into the sniff port.
2. Connect the sniffer line before you press the “Start / Stop” button when in sniff
mode.
If the sniffer line is removed during operation, the device reports an error. The device
also reports an error when the sniffer line is not connected and “Sniff” operating mode
is active. The sniffer probe can be connected whether in sniff mode or in vacuum mode.
A selection of appropriate sniffer probes is listed in the Accessories section.
Multi-Use Ports
Table 11 summarizes the port configurations and locations for all TITAN VERSA
configurations. Ports include:
• Vacuum vent
• Pump exhaust
• Oil drain and oil fill
