Table 2-9. Hopper Specications
ITEM SPECIFICATION
Material Capacity 7.5 Tons
Height 23 in
Wings 3/8 in
Figure 2-10. Screed Specications
ITEM SPECIFICATION
Screed Weight
Standard Screed 815HD (Option)
3000 lbs 3700 lbs
Electric Heat (Option)
Two (2) 1750-watt electric
heat elements on main
screed.
One (1) 1000-watt electric
heat element on each
screed extension.
Two (2) 2000-watt S-Curve
electric heat elements on
main screed.
One (1) 1000-watt electric
heat element on each
screed extension.
Main Screed Width 8 ft
Screed Extensions
Two (2) 44-inch Hydraulically-Operated
WIDTH: 3 ft 6 in each
Extension Width of Wear Plate 7 in
Bullnose Radius 1.37 in
Vibration Two (2) electric vibrators producing 4000 vpm.
Crown/Valley Adjustable, 2-inch crown, 1-1/2 inch of valley
Table 2-11. Generator Specications
ITEM SPECIFICATION
Power 10 kW
Voltage 240 Volts
Frequency 60 Hz
LeeBoy 8515E Conveyor Paver
2-6
Information and Specications
