LeeBoy 8515E - Diagnostics

4-8 LeeBoy 8515E Conveyor Paver
Operation
Logged DiagnosticsLogged Diagnostics
The Logged Diagnostics screen displays nonactive
warnings or faults with the appropriate Suspect Param-
eter Number (SPN) and Failure Mode Indicator (FMI)
that are stored in the system. (Figure 4-10) Use the
UP/DOWN soft keys to scroll through list if needed.
NOTE: Select the Freeze Frame ( ) button to
request that frame data from the ECU when
faults are present.
Figure 4-10. Logged Diagnostics Screen
DiagnosticsDiagnostics
Use the UP/DOWN soft keys and stop the cursor (>) for
to view either active or logged diagnostics, then press
the Select ( ) soft key. (Figure 4-8)
Figure 4-8. Diagnostics Screen
Active DiagnosticsActive Diagnostics
The Active Diagnostics screen displays active warn-
ings or faults with the appropriate Suspect Param-
eter Number (SPN) and Failure Mode Indicator (FMI).
(Figure 4-9) It may also display text description and ID/
Name of the device that transmitted the message. Use
the UP/DOWN soft keys to scroll through list if needed.
Figure 4-9. Active Diagnostics Screen
