44
LeeBoy 8515E Conveyor Paver 4-11
Operation
Status Icon Description
Diesel Particulate Filter Lamp — A
Solid Lamp is the initial warning that
soot levels are rising in the DPF. A
Flashing Lamp indicates a DPF REGEN
is needed (on some systems, the
lamp will become RED when ashing).
The lamp will turn solid again when a
REGEN is initiated.
Any time the lamp begins ashing, the
operator should increase the loading
on the engine so that regeneration is
possible.
If increased load does
not cause an automatic REGEN
to occur, the operator should
immediately perform a Parked,
Manual REGEN (see reverse side for
instructions).
DPF Regeneration set to Inhibit — The
user may choose to inhibit the REGEN
if conditions are too hazardous for high
exhaust temperatures. When this lamp
is illuminated, a REGEN cannot be
performed and soot levels will continue
to rise.
Unless hazardous
conditions exist, the REGEN Inhibit
switch and this lamp should remain
off.
User SettingsUser Settings
This screen displays the following action items: Screen
Color; Brightness; Language; Units; Date and Time.
Screen ColorScreen Color
Use the UP/DOWN soft keys and stop the cursor (>)
next to the action item Colors. (Figure 4-17 and 4-18)
Set your preference for day or night vision using the +/–
soft keys.
Figure 4-17. Set Night Vision Color Preferences
Screen
Figure 4-18. Set Day Vision Color Preferences
Screen
