LeeBoy 8515E Conveyor Paver 3-7
Component Location
ITEM
NO.
CONTROL
NAME
FUNCTION
4
Truck Hitch
(Option)
Optional Component: Engages truck hitch function. Engages the truck hitch to the material truck
wheels. Set switch to the IN position to engage the hitch. The OUT position disengages hitch
from the material truck wheels.
5 Ignition Starts and stops engine.
6
PV480 Digital
Display
Displays paver setup and calibration information, engine operating information, and engine and
paver system fault information.
7 Wait to Start Light Illuminates for a few seconds during start-up. Starter will not engage until this light turns off.
8 2-Speed Light Illuminates when paver is in high gear.
9 Plus One Light
The Plus One status light illuminates and blinks to alert the operator of a fault in the Plus One
controller that monitors paver control systems.
10 Conveyor Lift Controls raising and lowering conveyor bed.
11
Beacon and Work
Lights
Used to alert surrounding vehicles and pedestrians. The beacon light also comes on when the
work lights are turned on.
12 Vibrators Switch
Turns the screed vibrators on and off, but only functions when joysticks are in the forward
position. The screed vibrator helps compact material.
13
Grade Control
Switch
When this switch is in the GRADE position, the tow point switches are enabled regardless of the
Run/Start switch position. When in the SLOPE position, the tow point switches are controlled by
the automated system when joysticks are in the FORWARD position.
14
Right Tow Thicker/
Thinner Switch
Sets the thickness of the asphalt and controls the electric ight screws. Operator can select
either THICKER or THINNER as needed. The Grade Control switch must be set to GRADE on
the control panel to turn power on for this feature.
15
High/Low 2-Speed
Gear Switch
Used to change machine speed. Place switch in HIGH position for travel (High/Low Gear light
will illuminate). Pave only in LOW speed. NEVER pave in high speed.
16 Horn Pressing this button sounds the horn.
17 E-Stop Button
Immediately stops the paver engine and all electronic functions. Turn clockwise to release
E-Stop button.
18
Left and Right
Conveyor Switches
Selects automatic or manual mode for left and right conveyors. MANUAL position provides
override. The center position is OFF. For automatic operation, set switch to AUTOMATIC.
19
Screed Lift/Float
Switch
Raises or oats the screed. When released, switch automatically returns to the center to hold
the screed in selected position. Flip switch to RAISE to raise the screed. Set the switch to
FLOAT to oat the screed (switch will lock in the FLOAT position).
20
Left Extension
Switch
Extends or retracts left screed extension. (Switch also located on the remote box on left side of
paver.) Push switch IN to retract left screed extension. Push switch to OUT to extend left screed
extension.
21
Left and Right
Under Auger
Material Cut-Off
Switches
Opens and closes left and right Under Auger Material Cut-Offs.
22 Hopper Switch
Opens and closes hopper side wings. Push switch to the OUT position to open hopper wings.
Push switch to the IN position to close hopper wings.
23
Right Extension
Switch
Extends or retracts right screed extension. (Switch also located on the remote control box.
Push switch IN to retract right screed extension. Push switch to OUT to extend right screed
extension.
