SPN FMI DTC SYMPTOM/CAUSE RECOVERY FROM ERROR
523598 2 CAN EBC1 frame error. CAN EBC1 frame time-out error. Diagnostic counter = zero
523599 0
All exhaust temperature
sensor failure.
All exhaust temperature sensor failure
(sensor low) simultaneously.
Diagnostic counter = zero
523600 0
Initial pump calibration
incomplete.
Initial pump calibration incomplete. Diagnostic counter = zero
523601 0
High exhaust gas
temperature after
emergency high
temperature DTC.
All exhaust temperature (T0, T1, T2)
reduces down to 572° F (300° C).
Engine stops.
Diagnostic counter = zero
523602 0
High frequency of
regeneration.
Regeneration time interval within
30 minutes occurs three times
continously. EGR stops.
Key switch turn OFF.
523603 15 Overheat precaution.
Engine coolant temperature ≥ 230° F
(220° C).
Diagnostic counter = zero
523604 2 CAN1 bux off. CAN1 bus off. EGR stops. Key switch turn OFF.
5
