Auger And Inner Bearing
1. Remove rear grating over auger assembly.
2. Run screed extension all the way out.
3. Remove two (2) nuts holding top cover on and pry
cover apart.
4. Clean asphalt build up from around cover.
NOTE: Heating asphalt may be required.
5. Remove bottom portion of cover by laying on
conveyor under engine [six (6) bolts].
6. Rotate augers so that master link is centered at
front.
7. Loosen auger chains by sliding auger motors down
from backside after loosening the two (2) bolts
securing mounting brackets.
8. Remove bottom clamps that hold auger bearings in.
NOTE: Roll pin is used to line up bearing grease hole
with the grease tting hole. If installed improperly,
no grease will get to bearing.
9. Remove auger end mounts so that augers can be
removed through opening in sides.
10. Remove augers and lay augers on the ground in
the same position as removed. This will help insure
proper installation of the new augers.
11. Check inner auger bearing and replace at this time
if faulty.
NOTE: When installing the new augers, be sure
to align augers the same as the removed
augers. It is very easy to install augers
backwards.
NOTE: When installing auger, make sure roll pin
is aligning grease tting hole with grease
tting before tightening clamps on inner
auger bearings.
1. Install new augers making sure that they are on
correct side to auger material outward.
2. Tighten bearing setscrew to help hold auger shaft
from moving outward.
3. Slide auger collar on end of auger shaft and bolt
end mount back on. Torque mounting bolts to 78 ft.
lbs. (106 N•m)
4. Push collar all the way in against end mount and
attach with two (2) setscrews, one (1) on outside and
one (1) on inside.
Conveyor Drive Motors
1. Remove hydraulic hoses from motor.
2. Remove four bolts holding hydraulic motor to slide
mount.
3. Slide drive motor out of slide mount.
4. Slide new or repaired drive motor into slide mount.
5. Secure with four bolts.
6. Reconnect hydraulic hoses to motor.
7. Check for leaks.
Cut-Off Assembly
1. Remove clevis pin that connects the cutoff cylinder
to the cutoff.
2. Remove roll pin out of outer cutoff hinge.
3. Insert a 3/8” bolt in the end of the hinge pin to use to
remove pin.
4. Cutoff will slide down.
5. Clean area around cutoff hinge.
6. Align cutoff hinge.
7. Grease and insert hinge pin.
8. Insert roll pin into outer cutoff hinge.
9. Connect cylinder back to cutoff.
5
LeeBoy 8616B Conveyor Paver 5-25
