GENERAL INFORMATION
The LeeBoy Model 8616B Conveyor Paver is equipped
with hydrostatic-driven tracks that propel the paver
using friction-controlled joysticks. The two joysticks
control the speed and direction of the paver in
conjunction with the machine speed setting. Ramping
for acceleration and deceleration are proportional to the
movement of the joysticks. (Page 3-5)
The propel system utilizes a dual path proportional
system to control the tracks. In low speed, the inside
track counter-rotates.
Steering the tracks is controlled by a hydraulic
proportional pump. The amount of steering is controlled
by the amount of joystick movement and the speed of
the paver. As the paver speed increases, steering will
be reduced.
Engine RPM is set manually by using the throttle up
and throttle down buttons located on the DP700 digital
display unit on the operator control panel. Always set
throttle before starting to pave.
The engine RPM automatically increases to 1800 RPM
when the conveyor or augers are engaged.
If the joysticks are set to the neutral position for 10
seconds, the engine will idle. When the joysticks are
taken out of neutral, the engine immediately returns to
the last set RPM.
Only authorized personnel who are
properly trained should operate the LeeBoy Model
8616B Conveyor Paver.
RECEIVING THE MACHINE
Although the machine has been checked thoroughly by
the manufacturer, road hazards or other factors during
transport may result in damage. Be sure to check the
machine thoroughly before operating it:
1. Check engine oil. (Page 5-17)
2. Check hydraulic uid level. (Page 5-19)
3. Check machine hoses for any damage or leaks.
4. Inspect machine for any damage during transport.
Contact your authorized dealer immediately if any
damage has occured.
Initial and Daily Inspection
The following inspection is essential and should be
performed before the initial start-up. Visually inspect the
unit to check its general condition and for familiarization.
Continue with a check of the systems and components
shown in Table 4-1 below:
Only trained personnel should operate
the LeeBoy 8616B Conveyor Paver.
Table 4-1. Initial Inspection
INSPECT PROCEDURE
Engine Oil
Level
Maintain oil level between ADD and
FULL marks on dipstick.
Fuel Tank
Check for adequate fuel supply. Fill if
needed. Always ll tank at end of the day
to prevent condensation in the tank.
Hydraulic
Tank
Check the tank for oil level and leaks.
Radiator Check coolant level.
Battery
Ensure all cables are tight and clean.
Check for corrosion on the battery
terminals.
Air Cleaner
Check the air lter element and hose
connections. Air cleaner has both a
primary and secondary lter.
Drain Plugs Make sure plugs are inserted and tight.
Engine Belt Check for proper belt tension.
Grease
Fittings
Ensure ttings are greased and in good
working order.
4
Operation
LeeBoy 8616B Conveyor Paver 4-3
