MAIN HARNESS ELECTRICAL (6 OF 6)
Schematic for Part # 1011249
POWER
CROWN
PIN
COLOR
FUNCTION
A
POWER CROWN POWER
B
POWER CROWN DOWN
C
POWER CROWN UP
6
5N
Figure 6-15. Main Harness Electrical (6 of 6)
LeeBoy 8616B Conveyor Paver 6-31
Schematics
