Track Assembly - Poly Pads Parts List
Item
No
Part Number Qty Description Remarks
1 1007024SRV 1 Assembly, Screed Arm Mount, Left
Ref 1007025SRV 1 Assembly, Screed Arm Mount, Right Not Shown
2 100-16-14-40-5F 3 Capscrew, Hex Head, 1-14 x 2.5
3 986836 3 Washer, Lock, 1.00, Nord Wedge
4 851566 8 Track Roller
Ref 1007656 A/R Bar, Roller Spacer, 1/4” Not Shown
5 100-M12-1.75-60-10.9 23 Capscrew, Hex Head, M12 x 1.75 x 60
6 986810 43 Washer, Lock, 0.500
7 1006693 1 Front Bogie Roller
8 1006691 4 Bushing, Bogie Roller
9 1006686 2 Bogie Shaft w/Flange
10 100-10-18-32-5 20 Capscrew, Hex Head, 0.625-18 x 2.00
11 1006692SRV 1 Idler Bogie Roller
12 1010432 2 Track Assembly, Poly Pads, 140mm
Optional Complete As-
sembly
Ref 1008900 2 Track, Poly, 14” Molded, 40 Links, 140mm
Standard Complete As-
sembly
13 1007003-04 A/R Chain, 140mm, 40 Links
14 1007003-05 1 Pad, Molded with Poly, 140mm Chain
15 1007003-08 160 Grouser Bolt
16 1007003-09 160 Grouser Nut
17 1007003-07 1 Master Pin, Chain, 140mm
18 1007003-06 A/R Grouser without Pad
19 1007003-01A A/R Pad, Poly, Bolt-On Replacement Option
20 1007003-10 160 Nut, Poly Pad
21 1008730SRV A/R Assembly, Guide Bar, Left
22 1007656 Roller Spaces
Ref 1008724 A/R Plate, Guide Bar Mount
Ref 1008728 A/R Rod, Guide Bar
Ref 1008727 A/R Weldment, Rod, Guide Bar
Ref 920070 A/R Thumb Screw, 0.375-16 x 1.00
Ref 858206 A/R Chain, Proof Coil, .250 x 10 Link
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-5
