LeeBoy 8616B - Page 186

Engine Assembly with Pumps Parts List
Item
No
Part Number Qty Description Remarks
1 1009384 1 Engine, Kubota, Tier 4i, 99 HP
2 1006952 1 Pump, Hydraulic, Tandem
3 1006956 1 Pump, Hydraulic, Right
4 1011524 1 Weldment, Radiator Shroud
5 300-6 16 Washer, Flat, 3/8”
6 118-3 8 Washer, Lock, 3/8”
7 116-3 8 Nut, Hex, 3/8-16
8 100-6-16-16-5F 8 Capscrew Hex Head, 3/8-16 x 1
9 12757410 1 O-Ring
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-15
