Hydraulic Components Parts List
Item
No
Part Number Qty Description Remarks
1 1007087 1 Hydraulic Tank
2 1007095 2 Strainer, Hydraulic Suction
4 1011698 1 Valve, Gate, 2"
5 140640 1 Valve, Gate, 1.25
6 290030 1 Filter Element, Hydraulic Charge
7 290010 1 Head, Hydraulic Charge/Return Filter
8 980350-01 1 Hydraulic Filter Element
9 982940 1 Filter Housing Assembly, Hydraulic
10 500070 1 Gauge, Sight Level/Temp, Hydraulic Oil
11 1011735 1 Manifold, Hydraulic, 12-Station
12 983643-01 1 Solenoid Valve Side Wing
Ref 983643-01 1 Solenoid Valve Auger Lift
Ref 983643-01 1 Solenoid Valve Left Cutoff
Ref 983643-01 1 Solenoid Valve Left Ext
Ref 983643-01 1 Solenoid Valve Left Tow
Ref 983643-01 1 Solenoid Valve Right Tow
Ref 983643-01 1 Solenoid Valve Right Cutoff
Ref 983643-01 1 Solenoid Valve Right Ext
Ref 983643-01 1 Solenoid Valve Left Slope
Ref 983643-01 1 Solenoid Valve Right Slope
13 983643-02A 20 Coil, 12 VDC
14 983643-03 20 Nut, Coil
15 987220-04 1 Valve, Reducing
16 987220-05 1 Valve, Relief
17 983643-04 2 Solenoid Valve Screed Raise/Lower
18 983643-05 8 Valve, Dual Check
19 983643-08 23 Valve, Check
20 983643-10 1 Flow Divider
21 987220-06 1 Solenoid Valve Generator Function
22 986992-03 2 Valve, Check Toe Point Only
23 987220-07 2 Valve, Counterbalance Toe Point Cylinder
Ref 983643-11 A/R Cover Plate, Valve Not Shown
Ref 987220-01 A/R Plug Not Shown
Ref 987220-02 A/R Plug Not Shown
Ref 983643-09 A/R Valve, Check Not Shown
Ref 988657-01 A/R Valve, Check Not Shown
Ref 980286 1 Plate, Hydraulic Output Not Shown
24 620050 1 Breather Cap, 1/4”
Ref 910122 1 Manifold, Hopper Wing Sequence Not Shown
Ref 910122-1 A/R Valve, Relief Not Shown
25 989202 1 Hydraulic Temperature Sensor
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-23
