Generator Parts List
Item
No
Part Number Qty Description Remarks
1 1011534 1 Generator, Hydraulic, Assembly
2 1008513-02 1 Motor, Generator
3 985138-03 1 Power Cord, Bulkhead to Control Box
4 985825 1 Harness, Electric Heat, Generator-to-Bulkhead
Ref 986658 1 Capacitor, Generator, 40 uF Not Shown
Ref 1002148 1 Capacitor, Generator, 30 uF Not Shown
Ref 1002147 1 Capacitor, Generator, 25 uF Not Shown
Ref 1002146 1 Capacitor, Generator, 20 uF Not Shown
Ref 989259SRV 1 Kit, Extension Harness Not Shown
5 1011538 1 Generator, 12kW (w/out Motor)
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-27
