Hoods and Covers Parts List
Item
No
Part Number Qty Description Remarks
1 1010587 1 Assembly, Engine Cover, Tier 4
2 1006981 1 Front Access Door
3 1006983 1 Access Door Hinge
4 1007035 1 Plate, Pump Vent
5 1007034 1 Plate, Right Top Cover
6 1007016 2 Plate, Hood Support
7 1007015 1 Plate, Left Top Manifold Cover
8 980417 2 Assembly, Top Back Plug
9 980460 6 Lever Latch
- 35560 2 Key, Lever Latch Not Shown
10 1012563 2 Light, Led Circular
11 1010158 2 Bracket, Oil Cooler Mount
12 852260 1 Cooler, Hydraulic Oil Assembly Complete
13 853963 1 Tool Box, w/Mounting Holes
14 211748-02 1 12-24 VDC Strobe Light
15 989469SRV 1 Assembly, Beacon Light Post
16 985234-01 1 Manual-Pak Case, 10.5 x 13.5 x 2.5
17 1008893 1 Weldment, Right Cover, Fuel Tank
18 1007039 1 Assembly, Access Door, Right
19 160450 2 Latch, Engine Access Panel Door
- 35560 2 Key, Engine Access Panel Door Not Shown
20 1011508 1 Weldment, Upper Cover w/Deectors, Left
21 1007044 1 Rod, Hinge Access Door
22 1007038 1 Assembly, Access Door, Left
23 1008892 1 Cover, Generator/Battery
24 1010276 1 Weldment, Cover, Lower, Left
25 1007088 2 Lid, Access Door
26 987639 4 Hinge, (2) Thru Holes
27 3200DI 1 Water Tight Connector, 1/2 x 1/2 Optional
28 1006179 1 Weatherproof Outlet Box Optional
29 1007018 1 Toe Board, Left Side
30 1007019 1 Toe Board, Right Side
31 1010539 1 Weldment Grating,Floor
32 1010537 1 Weldment Grating, Floor Board, Left
33 1010275 1 Weldment, Cover, Lower, Right
34 1011536 4 Bar, Shroud Hold-Down, Side
35 1011526 1 Weldment, Deector, Engine Heat
36 1011527 2 Shroud, Rubber, Side
37 900144 1 Sensor, Hydraulic Oil Temperature
38 982792 1 Fan, Oil Cooler
