LeeBoy 8616B - Page 206

Spray Down Parts List
Item
No
Part Number Qty Description Remarks
1 920200 1 Hose Reel, Machine Washdown
2 920220 2 Handle & Nozzle, Spraydown
3 901210A A/R Nozzle, Fuel Washdown
4 480160 1 Valve, Ball 3/8”
5 31959 1 Fitting, 06MP-06HB, Push-On
6 853211085 1 Fitting, 90 06MP-06MP
7 5404-06-02 1 Adapter, Hex Pipe Nipple
8 1011844 1 Switch, Pressure, 10 psi
9 1011781 1 Mount, Spraydown Pump, Facet
10 1011738 1 Pump, Spray Down, Facet
11 118-6 2 Washer, Lock, 5/8”
12 2120-6-2-B 1 Fitting, Elbow, Brass, 90 Degree
13 6274 1 Fitting
14/15 6352 1 Hose, Pump to Hose Reel, 5’ Cut to length
16 5406-6-2 1 Adapter, Reducer, Pipe, -6 / -2
17 1603-6-6-6 1 Adapter, Union, Triple Swivel
18 2605-6-6-6 1 Adapter, Male, Run Tee
19 200-4-20-5 2 Nut, Hex, 1/4-20
20 80694 2 Washer, Flat, 5/8”
21 300-4 2 Washer, Flat, 1/4”
22 100-10-11-32-5 2 Capscrew, Hex Head, 5/8-11 x 2
23 302-4 2 Washer, Lock, 1/4”
