LeeBoy 8616B - Page 212

Rear Auger Assembly Parts List
Item
No
Part Number Qty Description Remarks
1 981685 1 Assembly, Auger Motor Cover
2 100-8-13-16-5F 10 Capscrew, Hex Head, 0.500-13 x 1.000
3 118-5 22 Washer, Lock, 0.500
4 300-8 14 Washer, Flat, 0.500
5 200-8-13-5 16 Nut, Hex, 0.500-13
6 981695SRV 1 Cover, Auger Support
7 100-5-18-16-5 8 Capscrew, Hex Head, .313-18 x 1.000
8 302-5 10 Washer, Lock, .313
9 981688 1 Chain Cover
10 1009133 2 Motor, Hydraulic, Gear, 4-Bolt
11 981696 2 Mount, Motor
12 240350 2 Sprocket, 60B 12 x 1.00-6 Spline
13 985815 2 Chain, Roller, 60H x 51 Pitch
14 100-5-18-12-5F 2 Capscrew, Hex Head, 0.313-18 x 0.750
16 119-2 2 Washer, Flat, 0.313
17 100-8-13-20-5F 8 Capscrew, Hex Head, .500-13 x 1.250
18 100-10-11-22-5F 4 Capscrew, Hex Head, .625-11 x 1.375
19 118-6 12 Washer, Lock, .625
20 80694 4 Washer, Flat, .625
21 102-6-16-24-F 6 Capscrew, Hex Head, .375-16 x 1.500
22 1007270 2 Shaft With Sprocket, 12” Auger Include 23, 24
23 1007323 2 Washer, Auger Bearing Spacer
24 1007267 2 Bearing, Auger
25 1007269 2 Clamp, Auger, 12”
27 1007306 2 Assembly, Spacer, Auger Shaft
28 981700L 4 Auger Flight, Left, 12”
Ref 981700R 4 Auger Flight, Right, 12”
Ref 1007304SRV A/R Complete Auger Assembly, Left
Ref 1007305SRV A/R Complete Auger Assembly, Right
29 Same as 18 8 Capscrew, Hex Head, 0.625-11 x 1.375
30 80042 8 Nut, Hex, 0.625-11
Ref 860051HDLSRV 1 Auger Mount, Left Include 31, 32, 33
Ref 860051HDRSRV 1 Auger Mount, Right Include 31, 32, 33
31 851645SRV A/R Collar, Auger Shaft End
32 810070 A/R Bushing, 2.00 ID x 2.50 OD x 2.50 Idler
33 851646 A/R Plate, Hopper Wing Corner 855313SRV
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-41
