LeeBoy 8616B - Page 216

Screed Frame Assembly - Electric Parts List
Item
No
Part Number Qty Description Remarks
1 1007195 1 Group, Screed Frame, 815HD
2 983157 1 Assembly, Turnbuckle w/Ratchet
3 980182 1 Assembly, Crown & Valley, Rear
4 1008047 1 Chain, Roller, 60H x 39 Pitches
5 985125 2 Cover, Elements, Screed Base
6 981659 2 Pin, Slope
7 981711 2 Plate, Pivot Cover
8 981661 2 Pin, Cylinder Mount
9 985121 4 Bar, Element, Hold-Down
10 1007276SRV 4 Element, Heater 1500W
11 1007002 2 Cover, Rear Elements
12 1008056SRV 1 Wearplate, 1/2 Wear Plate w/Studs
Include 10, 11, 28, 29;
Not 9
13 1008663SRV 1 Weldment, Rail Mount, Left
14 1008662SRV 1 Weldment, Rail Mount, Right
15 1006425 2 Bar, V-Groove Top Rail
16 1006426 2 Bar, V-Groove Bottom Rail
17 1011697 2 Weldment Cover, Screed
18 1008758 1 Assembly, Upper Screed Cover, Right
19 1008757 1 Assembly, Upper Screed Cover, Left
20 1007000 1 Cover, Screed Lower
21 981710R 1
Cylinder, Hydraulic, 2.00 x 2.00 x 4.200 x
1.25
22 981710L 1
Cylinder, Hydraulic, 2.00 x 2.00 x 4.200 x
1.25
23 983421 1 Cylinder, Hydraulic, 2.75 x 2.00 x 11.25 Rod
24 102-102-1A 4 CSHH, 0.312-18 x 50, GR5
25 118-2 4 Washer, Lock, 0.312
26 102-107-1A 6 CSHH, 0.312-18 x 1.50, GR5
27 118-2 6 Washer, Lock, 0.312
28 116-5 24 Nut, Hex, 0.500-13
29 118-2 24 Washer, Lock, 0.312
30 102-6-16-16-5F 12 Capscrew, Hex Head, 0.312-18 x 1.50
31 102-305-1A 20 Capscrew, Hex Head, 0.437-14 X 1.00
32 118-4 20 Washer, Lock, 0.437
33 102-409-1A 12 Capscrew, Hex Head, 0.500-13 x 2.00
34 116-5 12 Nut, Hex, 0.500-13
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-45
