Walk Board Assembly Parts List
Item
No
Part Number Qty Description Remarks
1 987056SRV 1 Walkboard, Assembly
2 985163 2 Plate, Walkboard Hinge
3 102-406-1A 2 Capscrew, Hex Head, 0.500-13 x 1.25
4 118-5 2 Washer, Lock, 0.500
5 116-5 2 Nut, Hex, 0.500-13
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-47
