LeeBoy 8616B - Page 226

Screed Extension (Right) Assembly Parts List
Item
No
Part Number Qty Description Remarks
1 1006380SRV 1 Assembly, Extension Heatbox Does not include 4, 5
2 1008665SRV 1 Weldment, Heatbox Cover
3 985123 3 Clamp, Element, Screed Extension
4 985120 1 Bar, 0.25 x 1.5 x 36
5 1007278SRV 1 Element, Heater, Screed, 41”
6 1006379SRV 1 Assembly, Screed Extension, Right Includes all items
7 1006400 1 Plate, Extension Strike-Off
8 1006395 2 Bar, Vertical Lift
9 1008664 1 Weldment, Extension Vibrator Cover
10 1006398 1 Plate, Extension Access Cover
11 854447SRV 1 Rnd., 0.688 x 43.50
12 1006397 2 Bar, Vertical Lift Gauge
13 1007098SRV 1 Outer Extension Mount, Right
14 1007099SRV 1 Inner Extension Mount, Right
15 1006536 1 Plate, Endgate Bracket w/Holes
16 1006390 2 Assembly, Vertical Lift Adjustor
17 1006401 1 Assembly, AOA Adjustor
18 1000947 1 Ball Joint, 0.750, Male
19 102-111-1A 14 Capscrew, Hex Head, 0.312-18 x 2.50
20 118-2 14 Washer, Lock, 0.312
21 100-6-16-16-5F 6 Capscrew, Hex Head, 0.375-16 x 1.00
22 118-3 6 Washer, Lock, 0.375
23 102-307-1A 3 Capscrew, Hex Head, 0.437-14 x 1.50
24 118-4 3 Washer, Lock, 0.437
25 116-4 3 Nut, Hex, 0.437-14
26 100-6-16-5F 6 Capscrew, Hex Head, 0.375-16 x 1.00
27 118-3 6 Washer, Lock, 0.375
28 116-3 6 Nut, Hex, 0.375-16
29 102-103-1A 6 Capscrew, Hex Head, 0.312-18 x 0.75
30 118-2 6 Washer, Lock, 0.312
31 102-103-1A 4 Capscrew, Hex Head, 0.312-18 x 0.75
32 118-2 4 Washer, Lock, 0.312
33 100-6-16-16-5F 2 Capscrew, Hex Head, 0.375-16 x 1.00
34 118-3 2 Washer, Lock, 0.375
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-55
