Screed Pull Arm (Left) Assembly Parts List
Item
No
Part Number Qty Description Remarks
1 1008240SRV 1 Assembly, Screed Control
2 1007030SRV 1 Assembly, Screed Arm, Left
3 980439 2 Bar, Screed Arm Stop
4 980441 2 Tube, Arm Inner Roller Stop
5 102-911-1A 2 Capscrew, Hex Head, 1.000-8 x 2.50
6 200-16-8-5 2 Nut, Hex, 1.00-8
7 851373SRV 1 Lock Arm, Flight Screw
8 102-202-1A 4 Capscrew, Hex Head 0.375-16 x 0.50
9 118-3 4 Washer, Lock, 0.375
10 116-3 4 Nut, Hex, 0.375-16
11 988924-03SRV 1 Switch, Emergency Stop, Assembly
12 851392 1 Switch, Toggle, 3-Position
13 1008917 1 Tube, Screed Box Pivot
14 35049 1 Knob, 0.25 Shaft
Ref 1001822-05 1 Potentiometer, Rear Pump Speed
15 851090613 1 Switch, Toggle, Spdt., 3-Position
Ref 1008934 1 Screed Plate Assembly, Main
Ref 851156 1 Knob, Round Ball, 1.375 x 0.375-16
16 1012563 1 Light, LED, Circular
Ref 981503 1 Cylinder, Hydraulic, Toe Point Not Shown
Ref 981503-01 A/R Seal Kit, Toe Point Not Shown
Ref 851436SRV 1 Cylinder, Hydraulic, 2.00 x 12.00 x 1.00 Rod Not Shown
Ref 910145-01 A/R Seal Kit, Hydraulic Cylinder, 2.00 x 1.00 Not Shown
17 982249 1 Switch, Push Button
18 1008928 1 Weldment, Screed Control Box
19 1007346 1 Decal, Screen Control Box
20 851436SRV 1 Cylinder, Hydraulic 2.00 x 12.00 x 1.00 Rod
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-69
