Electric Heat Control Assembly (Standard) Parts List
Item
No
Part Number Qty Description Remarks
1 1010397-01 1 Enclosure, Electric Heat w/Holes
2 31983 1 Light, Red, .50 Hole
3 851391 1 Switch, Toggle, 2-Position
4 982249 1 Switch, Push Button
5 985142 1 Timer, Electric
6 985138-04 1 Block, Terminal
7 1009228 12 Circuit Breaker, 10 Amp
8 985143 1 Decal, Electric Heat Control Box (Standard)
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-75
