Screed Heat Control Box w/Heated Endgates (Optional) Parts List
Item
No
Part Number Qty Description Remarks
1 1011311-01 1 Enclosure, Electric Heat w/Heated Endgates
2 31983 1 Light, Red, .50 Hole
3 851391 1 Switch, Toggle, 2-Position
4 982249 1 Switch, Push Button
5 985142 1 Timer, Electric
6 985138-04 1 Block, Terminal
7 1009228 12 Circuit Breaker, 10 Amp
8 72086 1 Switch, Toggle, 2-Position
9 1011180 1 Decal, Heat Control Box, Endgates
SCREED HEAT CONTROL BOX W/HEATED ENDGATES (OPTION)
"
"
9
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-77
