LeeBoy 8616B - Page 252

Screed Heat Control Box Parts List
Item
No
Part Number Qty Description Remarks
GRP 1008064 GRP Screed, Power Crown Complete Assembly
1 1008168SRV 1 Cover, Power Crown
2 1008667SRV 1 Weldment, Power Crown Center
3 1008600 1 Plate, Power Crown Adjuster
Does not include
bushing
- 1000960 1 Bushing, Composite, Power Crown
4 986640 1 Motor, Hydraulic
5 1008668SRV 1 Assembly, Crown & Valley Front
6 980182 1 Assembly, Crown & Valley, Rear Does not include # 7
7 1000798 2 Collar, Power Crown Locking
8 1008047 1 Chain, Roller, 60H x 39 Pitches
9 1000958 1 Chain, Roller, 50 x 18
10 1006419 2 Spacer, Crown Mount
11 1000799 1 Sprocket, #50 Roller Chain
12 100-6-16-16-5F 2 Capscrew, Hex Head 0.375-16 x 1.00
13 118-3 2 Washer, Lock, 0.375
14 102-405-1A 6 Capscrew, Hex Head, 0.500-13 x 1.00
15 118-5 6 Washer, Lock, 0.500
16 116-5 6 Nut, Hex, 0.500-13
17 102-406-1A 2 Capscrew, Hex Head 0.500-13 x 1.25
18 118-5 2 Washer, Lock, 0.500
19 116-5 2 Nut, Hex, 0.500-13
Ref 920238-3 A/R Cover, 3/4” Condulet
Ref 920238-2 A/R Condulet, 3/4” Aluminum
Ref 920238-4 A/R Gasket, Condulet Box, 3/4”
Ref 920238-5 A/R Aluminum Plug, 3/4” Condulet
Ref 3400DI A/R Water Tight Connector, 3/4” x 3/4”
20 1000059 2 Vibrator, Hydraulic
- 1008070SRV 1 Extension Vibrator Not Shown
21 72884 A/R Switch, Toggle, 2-Position
22 1007211 GRP Vibrator Extension Group Optional
23 960476A 1 Manifold, Citrus Tank Part of GRP 1007211
24 981941 1 Valve, Needle on Citrus tank Part of GRP 1007211
25 1008625 1 Hose Kit Part of GRP 1007211
26 1013563 1 Assembly, Screed Extension (Right), 12”
27 1013573 1 Assembly, Screed Extension (Left, 12”
28 985699-05 1 Hose Kit, Generator Screed Line Not Shown
29 1013843 2 Harness, 12” Extension Not Shown
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-81
