Paver Leveling Ski (30 - 40 Feet) Parts List
Item
No
Part Number Qty Description Remarks
GRP 851585SRV GRP 30 - 40 Feet Ski Assembly Complete Assembly
1 851249 2 Weldment, Skid
2 100-6-16-40-5 2 Capscrew, Hex Head, 3/8-16 x 2.50
3 204-6-16-5 3 Nut, Lock, Stover, 3/8-16
4 982005 2 Tube, Ski Foot Mount
5 851245 1 Spring, Extension
6 851246 24 Cable, .063
7 981981 6 Aluminum Cable Sleeve, 1/16”
8 1013865 2 Thimble, Cable, .063
9 212-6-16 2 Wing Nut, 3/8-16
10 1002311 1 Weldment, Rear Brace, 40’ Ski
11 1002302 1 Weldment, Front Brace, 40’ Ski
12 870307 2 Hair Pin Clip, Clevis Pin
13 87307 2 Pin, Position Lock
14 1002300SRV 1 Weldment, Ski Support Front Arm, 40’
15 851243LSRV 1 Weldment, Front Slide Bar Housing Left Side
16 851243RSRV 1 Weldment, Front Slide Bar Housing Right Side
17 1002305SRV 2 Weldment, Adjustable Slide Bar
18 920070 9 Thumb Screw, 3/8-16 x 1.00
19 851241RSRV 1 Weldment, Rear Slide Bar Housing Right Side
20 851241LSRV 1 Weldment, Rear Slide Bar Housing Left Side
21 1002301SRV 1 Weldment, Ski Support Rear Arm, 40’
7
Illustrated Parts List
LeeBoy 8616B Conveyor Paver 7-85
