Description Part Number Figure Number Item Number
Complete Box Assembly 1010496 7-36 1
Condulet, 3/4” Aluminum 920238-2 7-37 -
Conn, Nut, 24-Shell 981916-01 7-16 -
Connector, 03-Pin, Panel Mount 1010657 7-17 23
Connector, 03-Pin, Plug, W/120 Ohm 989179 7-17 24
Connector, 03-Pin, Socket 1000649 7-17 29
Connector, 03-Pin, Socket, Y 989178 7-17 27
Connector, 03-Pin, Wedge, Plug 983210 7-17 28
Connector, 31-Pin 981916 7-17 6
Connector, 47-Pin 1006000 7-17 14
Connector, Lock Washer 981916-02 7-17 4
Connector, Lockwasher, 24-Shell 981916-02 7-16 -
Connector, Nut 981916-01 7-17 5
Connector, Wedgelock 983211 7-17 26
Contact Block 1010692 7-17 9
Controller, 50-Pin, Propel 1012003 7-16 13
Controller, 50-Pin, Screed 1012004 7-16 14
Cooler, Hydraulic Oil Assembly 852260 7-13 12
Cord, Electronic Steering 851548-05 7-16 15
Coupling Half, 3-Jaw, 5/8” 280030 7-21 5
Coupling, Half, 3-Jaw, 1” 880030 7-21 3
Cover Plate, Valve 983643-11 7-9 -
Cover, 3/4” Condulet 920238-3 7-37 -
Cover, Auger Support 981695SRV 7-18 6
Cover, Back Panel 930065SRV 7-41 16
Cover, Elements, Screed Base 985125 7-19 5
Cover, Generator/Battery 1008892 7-13 23
Cover, Power Crown 1008168SRV 7-37 1
Cover, Rear Elements 1007002 7-19 11
Cover, Screed Lower 1007000 7-19 20
CSHH, 0.312-18 x 1.50, GR5 102-107-1A 7-19 26
CSHH, 0.312-18 x 50, GR5 102-102-1A 7-19 24
CSHH, 0.375-16 x 0.50 102-202-1A 7-31 8
CSHH, 0.500-13 x 1.00 102-405-1A 7-37 14
CSHH, 0.500-13 x 1.25 102-406-1A 7-37 17
Cutoff Assembly, Left 1006665SRV 7-18 44
Cutoff Assembly, Right 1006666SRV 7-18 -
Cylinder Hydraulic, Toe Point 981503 7-32 -
Cylinder, Hydraulic 2.00 x 12.00 x 1.00 Rod 851436SRV 7-31 20
Cylinder, Hydraulic 2.00 x 12.00 x 1.00 Rod 851436SRV 7-32 20
7
Alphabetical Parts Index
LeeBoy 8616B Conveyor Paver 7-97
