ITEM
NO.
CONTROL NAME FUNCTION
6 Horn Sounds horn.
7 Screed Lift Switch
Raises or oats the screed. Center position is hold. When released, switch
automatically returns to center position.
8
Right Auger Manual
Overide Switch
Center position is OFF. Pull switch down to manually overide right auger.
9 Right Extension Switch
Used to move the right extension in or out. Push switch to right arrow
(
) position to move right extension out. Push switch to left arrow ( )
position to move in the right extension.
10
Left Auger Manual
Overide Switch
Center positionis OFF. Pull switch down to manually overide left auger.
11 Hopper Wings Switch
Used to move the hopper wings in and out. Push switch to OUT position to
open hopper wings. Push switch to IN position to close hopper wings.
12 Right Cut-Off Switch
Used to open or close the right cutoff. Push switch to the OPEN position to
open right cutoff. Push switch to CLOSE position to close right cutoff.
13 Right Conveyor Dial
Controls right conveyor speed when Right Conveyor Switch is set to AUTO or
MANUAL. Turning clockwise increases conveyor speed.
14
Right Conveyor Sonic
Paddle Switch
Selects sonic or paddle override for right conveyor. Center is OFF position.
Set switch to SONIC position for conveyors to work with sonics. PADDLE
position controls conveyors with paddles.
15 Left Cut-Off Switch
Used to open or close the left cut-off. Push switch to the OPEN position to open
left cut-off. Push switch to CLOSE position to close left cut-off.
16 Left Extension Switch
Used to move the left extension in or out. Push switch to left arrow position to
move left extension out. Push switch to right arrow position to move in the left
extension.
17
Left Conveyor Sonic
Paddle Switch
Selects sonic or paddle override for left conveyor. Center is OFF position. For
sonic operation, set switch to SONIC position for conveyors to work with sonics.
PADDLE position controls conveyors with paddles.
18 Left Conveyor Dial
Controls left conveyor speed when Left Conveyor Switch is set to AUTO or
MANUAL. Turning clockwise increases conveyor speed.
19 Left Tow Switch
Sets the thickness of the asphalt. Place switch in THICKER position for thicker
asphalt. Place switch in THINNER position for thinner asphalt.
Component Location
