LEGRAND PDU - 0 U Button Mount

June 2018
Legrand PDU User Guide 19
0U Button Mount
Part Numbers:
 250-70-0140-00: button (2)
 250-70-0141-00: bracket (2)
 Slide flat brackets onto rear of 0U model and align over
holes at each end.
 Press button into bracket hole and turn with finger.
 Mount by positioning the PDU at the rack, then pressing
the buttons through the holes in the cabinet and letting
the PDU drop down slightly.
