Setting an Outlet's Cycling Power-Off Period
This section applies to outlet-switching capable models only.
This command determines the power-off period of the power cycling operation for a specific outlet.
config:# outlet <n> cyclingPowerOffPeriod <timing>
Variables:
 <n> is the number of the outlet that you want to configure.
 <timing> is the time of the cycling power-off period in seconds, which is an integer between 0 and 3600,
or pduDefined for following the PDU-defined timing.
Note: This setting overrides the PDU-defined cycling power-off period on a particular outlet. See Setting the
PDU-Defined Cycling Power-Off Period (on page 295).
Example - Outlet Naming
The following command assigns the name "Win XP" to outlet 8.
config:# outlet 8 name "Win XP"
Inlet Configuration Commands
An inlet configuration command begins with inlet. You can configure an inlet by using the inlet configuration
command.
Changing the Inlet Name
This command syntax names an inlet.
config:# inlet <n> name "<name>"
Variables:
 <n> is the number of the inlet that you want to configure. For a single-inlet PDU, <n> is always 1. The
value is an integer between 1 and 50.
 <name> is a string comprising up to 64 ASCII printable characters. The <name> variable must be
enclosed in quotes when it contains spaces.
