June 2018
140 Legrand PDU User Guide
Menu command Submenu command Refer to...
Role Based Access
Control
Creating Role Based Access Control Rules (on
page 168)
SSL Certificate Setting Up an SSL/TLS Certificate (on page 170)
Authentication Setting Up External Authentication (on page 173)
Login Settings Configuring Login Settings (on page 179)
Password Policy Configuring Password Policy (on page 180)
Service Agreement Enabling the Restricted Service Agreement (on
page 181)
Date/Time Setting the Date and Time (on page 182)
Event Rules Event Rules and Actions (on page 184)
Data Logging Setting Data Logging (on page 219)
Data Push Configuring Data Push Settings (on page 220)
Server
Reachability
Monitoring Server Accessibility (on page 221)
Front Panel Front Panel Settings (on page 224)
Serial Port Configuring the Serial Port (on page 224)
Lua Scripts Lua Scripts (on page 225)
Miscellaneous Miscellaneous (on page 229)
Configuring Network Settings
Configure wired, wireless, and Internet protocol-related settings on the Network page after connecting the
Legrand PDU to your network (on page 23).
You can enable both the
wired and wireless networking on Legrand PDU so that it has multiple IP addresses
-- wired and wireless IP. For example, you can obtain one IPv4 and/or IPv6 address by enabling one
Ethernet interface, and obtain one more IPv4 and/or IPv6 address by enabling/configuring the wireless
interface. This also applies when Legrand PDU enters the port forwarding mode so that Legrand PDU has
more than one IPv4 or IPv6 address in the port forwarding mode.
However, Legrand PDU in the BRIDGING mode obtains "only one" IP address for wired networking.
Wireless networking is NOT supported in this mode.
Important: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters
of ETH1, ETH2 and WIRELESS interfaces do NOT function.
To set up the network settings:
1. Choose Device Settings > Network.
2. To use DHCP-assigned DNS servers and gateway instead of static ones, go to step 3. To manually
specify DNS servers and default gateway, configure the Common Network Settings section. See
Common Network Settings (on page 142).
Static routes
and cascading mode are also in this section. You need to configure them only when
there are such local requirements. See Setting the Cascading Mode (on page 150) and Static
Route Exam
ples (on page 148).
3. To configure IPv4/IPv6 settings fo
r a wired network, click the ETH1, ETH2 or BRIDGE section. See
Wired Network Settings (on page 141).
