For concepts of thresholds, deassertion hysteresis and assertion timeout, see Sensor Threshold
Settings (on page 473).
5. Click Save.
Individual OCP Pages
An OCP's data/setup page is opened after clicking any OCP's name on the OCPs or Dashboard page. See
OCPs (on page 110) or Dashboard (on page 87).
General
OCP information:
Field Description
Label This OCP's physical number.
Status open or closed.
Type This OCP's type.
Rating This OCP's rated current.
Lines Lines associated with this OCP.
Protected Outlets Outlets associated with this OCP.
Inlet Inlet associated with this OCP.
This information is useful only when your
PDU has multiple inlets.
RMS current This OCP's current state and readings,
including current drawn and current
remaining.
To customize this OCP's name:
1. Click Edit Settings.
2. Type a name.
3. Click Save.
