1U/2U Legrand Clip Mount
Parts:
 Legrand Soluclip (2)
 Brackets (2): 1U or 2U size
 Attach brackets to ends of 1U model with screws, then
attach the Soluclip at each end by squeezing the
buttons together to insert the hooks through the bracket.
Release the buttons when the hooks are in position
securely through the bracket.
 Mount by positioning the PDU at the rack, then tilting
the PDU to press the hooks through the holes in the
rack. Then set the PDU back to level to engage the
hooks.
