Legrand PDU User Guide 313
Configuring the Cascading Mode
This command determines the cascading mode.
config:# network <mode> enabled <option1>
Variables:
 <mode> is one of the following cascading modes.
Mode Description
bridge The Bridging mode, where each cascaded
device is assigned a unique IP address.
portForwarding The Port Forwarding mode, where every
cascaded device in the chain shares the
same IP address, with diverse port
numbers assigned.
Important: When enabling either cascading mode, you must make sure the other cascading mode is disabled, or
the preferred cascading mode may not be enabled successfully.
 <option1> is one of the following options:
Option Description
true The selected cascading mode is enabled.
false The selected cascading mode is disabled.
 If Port Forwarding mode is enabled, you must configure two more settings to finish the
configuration:
On ALL cascaded devices, you must configure the 'role' setting one by one.
config:# network portForwarding role <option2>
On the master device, you must configure the 'downstream interface' setting.
config:# network portForwarding
masterDownstreamInterface <option3>
Variables:
 <option2> is one of the following cascading roles:
Role Description
master The device is a master device.
slave The device is a slave device.
 <option3> is one of the following options:
Option Description
ETH1, ETH2 ETH1, ETH2 port is the port where the 1st
slave device is connected.
Usb USB port is the port where the 1st slave
device is connected.
