Differences between the screen and the actual road
The composite images on the panoramic view monitor and guide lines give a
distance guide for flat road surfaces. Therefore, there is a margin of error between
the guide lines on the screen and the actual distance and course on the road.
■ When the ground behind the vehicle slopes up sharply
The distance guide lines will appear to
be closer to the vehicle than the actual
distance. Thus, objects on up-slopes will
appear to be farther away than they ac-
tually are. In the same way, there will be
a margin of error between the guidelines
and the actual distance and course on the
road.
8-2. Panoramic view monitor
331
8
Parking assist system
