1. Introduction VINX-1x0-HDMI Extenders – User's Manual 10
1.4. Features of the Device
Video Wall Application
The VINX devices can be arranged to a Video wall up to 8x8 Display devices. The displayed
video can be the same on each display, one image enlarged to all the sinks, or the mixture of
these.
Supporting 4K Resolution
1 Gigabit network with very low latency.
3D Signal Support
The extenders support the transmission of 3D content in 'Side-by-side' and 'Top-to-bottom'
modes.
Advanced EDID Management
The user can emulate any EDID on the inputs independently, read out and store any attached
ENC
DEC
Local HDMI Output
A display device can be connected to the Encoder for local signal checking. The port carries
the same video as the transmitted signal.
Frame Detector and Signal Analysis
The exact video and audio signal format can be determined such as timing, frequencies, scan
mode, HDCP encryption, color range, color space and audio sample rate.
Image Adjustment
Decoder side and videos can be freely cropped.
Built-in Website
device.
USB Extension
KVM extension for USB HID (Human Interface Devices, e.g. keyboard, mouse, presenter) and
Mass Storage devices (Flash drive, Hard drive).
RS-232
Serial Data Transmission
Transparent serial data transmission is available between the endpoints: Encoder and
Decoder devices.
1.5. Further Features of the AP-series
DIFFERENCE: Below mentioned features refer to the VINX-110AP-HDMI-DEC, VINX-120AP-HDMI-ENC
and VINX-210AP-HDMI-ENC models only.
Analog Video Support
The extra VGA input port allows connecting analog video which is converted to digital signal.
Analog Audio Support
External analog audio signal can embedded in the video stream at the Encoder side and can
be de-embedded at the Decoder side.
SFP Module Support
The devices can be connected to the network switch over SFP modules.
Remote Power (PoE)
The devices can be Powered over Ethernet (according to IEEE 802.3af) by a compatible power
source equipment.
Return Audio for a Microphone
Mono input port for a microphone from the Decoder towards the Encoder when the extender-
pair is used in Unicast mode. Includes a 20 dB gain in the signal path.
The audio of the HDMI signal can be transmitted as a 2-channel Dante® or AES67 source
